| 起源の場所: | 中国 |
| ブランド名: | sinotruk |
| 証明: | iso/ccc |
| モデル番号: | howo |
| 最小注文数量: | 1ユニット |
|---|---|
| 価格: | 交渉可能 |
| パッケージの詳細: | ヌード |
| 受渡し時間: | 30-45勤務日 |
| 支払条件: | L/C、T/T |
| 供給の能力: | 1か月あたり300ユニット/単位 |
| タイプ: | フェンス・セミトレーラー | 全体的な次元: | 13000mm*2550mm*1800mm |
|---|---|---|---|
| 証明: | ECE, Gcc, CE, ISO9001, DOT, CCC, ISO/Ts16949 | アウトリガー: | 単一の行動 |
| 車軸番号: | 3 必要 に かかっ て 軸 | 材料: | 堅い鋼鉄 |
| HSコード: | 8716100000 | ||
| ハイライト: | Jost 28ton Outrigger Lowbed Semi Trailer,13m Length Lowbed Semi Trailer,2550mm Width Lowbed Semi Trailer |
||
The 4 Axle Low Bed Semi Trailer is designed to meet the demanding needs of Nigeria's heavy-duty transport industry. It is ideal for carrying excavators, bulldozers, mining machinery, and other oversized loads across long distances. Built with high-strength Q345B steel and precise automatic submerged arc welding, it ensures unmatched durability and loading stability even on rough roads and construction sites.
| Item | Specification |
|---|---|
| Model | 4 Axle Low Bed Semi Trailer |
| Dimension (L ×W×H) | 13,000-17,000 × 3,000 × 1,650 mm (customizable) |
| Loading Capacity | 60-100 Tons |
| Main Beam | Q345B high-strength steel, H-beam height 500 mm |
| Axles | 4×13T / 16T Fuwa or BPW |
| Suspension | Mechanical spring suspension / air suspension optional |
| Tires | 12R22.5 or 315/80R22.5, 16 pcs |
| Brake System | Dual-line air brake, WABCO relay valve |
| King Pin | 50# / 90# interchangeable |
| Landing Gear | JOST 28T double-speed |
| Platform Height | 850-1200 mm |
| Ramps | Hydraulic or mechanical folding ramps |
| Paint | Anti-rust treatment + polyurethane topcoat (color customizable) |
